Based on the DT220 TECH platform, a brand new software system suitable for conference presentations and small performance.
| Digital Audio UHF Wireless System | |
DTT223-B Bodypack Transmitter |
*GAODIMIC® Products of the same brand and model are consistent with this product.
4th Generation Tech Platform
Application Scenarios
1. Picking up and forwarding various sound sources (instruments, harmonies, choruses) on stage; 2. High end conference scenarios. |
Characteristic
▪ Based on the "DT220 TECH" digital U-band wireless audio technology, it has the characteristics of stage performance sound quality, anti-interference, anti crosstalk, high fidelity, high signal-to-noise ratio, low background noise, and excellent wireless transmission distance. ▪ Digital U-band technology enables effective wireless transmission distance of up to 50 meters, effectively avoiding intermodulation interference. ▪ Ultra low power consumption, battery life>7 hours (lithium battery), standby time>20 hours. ▪ Adopting the patented technology of "mixed power", it can be powered by a 3.7V 14500 lithium battery or a 1.5V AAA No. 5 battery. ▪ Supports 5-12V phantom power supply. |
Parameters
| Communication Parameters | ||
Freq. Band | 510~590Mhz / 668~698 MHZ / 695~704 Mhz / 748~760Mhz, There are differences according to regions | |
Modulation Mode | Pi/4 DQPSK | |
Transmission Distance | >70m (MAX with flagship type Reciver)(Related to wireless environment) | |
Transmission Concurrency | Up to 48 simultaneous transmissions | |
| S/N | >100dB | |
Freq. Response | 20Hz-20KHz | |
Transmission Delay | <4ms | |
Distortion T.H.D | <0.03% (@1KHz) | |
| Sound Parameters | ||
| Mic Type | Suppor Earphones or Collar microphones,3.5mm Sennheiser’s Model | |
Sensitivity | - | |
| Freq. Response | - | |
Output Impedance | - | |
Directivity | - | |
| Physical and Electrical Indicators | ||
| Power Supply | 14500 Li battery *2 or AA battery *2 [Hybird Battery Tech] | |
Power Interface | - | |
Endurance | >5h(@14500 battery); >3.5h (AA battery) | |
Size | 92*62*19 (mm*mm*mm) / 52g(without battery) | |
Launch Connector | Cannon Interface | |
Function | Internal Antenna, Infrared,Phantom power supply |
Questions Frequently Asked
1. When charging lithium batteries with poor performance, their step-down circuit will interfere with the performance of the receiver. 2. When multiple devices are used simultaneously, improper frequency setting can easily lead to performance degradation due to intermodulation interference. |
Notes
|
Documents
| 1_Manual_EN_iweex (DTT223-B)Digital UHF Wireless System Bodypack Transmitter (freq.Group)_2024.07.14 |
Solution Refereced


Standard Accessories:
=========================
14500 Li-battery *2
Storage package *1
Manual *1
Qualification certificate *1
